Corn sowing machine | Maize planter machine
| Model | 2BYSF-6 |
| Size | 1.62*3.35*1.2m |
| row | 6 |
| Row spacing | 428-570mm |
| Plant spacing | 140mm-280mm |
| Ditching depth | 60-80mm |
| Fertilization depth | 60-80mm |
| Sowing Depth | 30-50mm |
| The capacity of the fertilizer tank | 18.75L x6 |
| The capacity of the seedbox | 8.5L x 6 |
| Weight | 425kg |
| Matched power | 50-80hp |
| Linkage | 3-pointed |
You can now ask our project managers for technical details
Corn sowing machine can sow a variety of crops including corn, peanuts, soybeans, cotton, and more. Compatible with tractors ranging from 12 to 100 horsepower, it offers multifunctional capabilities such as furrowing, fertilizing, seeding, soil casting, and soil pressing all in one operation.
The ditching depth ranges from 60-80mm, while the sowing depth is 30-50mm, ensuring optimal seed placement for germination. We specialize in a range of models including 2-row, 3-row, 4-row, 5-row, 6-row, and 8-row corn seeders, each tailored to meet specific farming needs.
It is very suitable for large-scale sowing, and the row spacing and plant spacing are adjustable, so it has a wide range of applications and a high seed emergence rate. Discover how our corn planter can streamline your planting process and maximize agricultural productivity.
What crops can a corn planter plant?
In addition to corn, the corn planter can also sow soybeans, cotton, grains, vegetables, and other crops.
Since the row spacing of each crop may be different, the planting row spacing of this machine can be adjusted. So it is suitable for a variety of crops.
The sowing depth of the corn planter can be adjusted during sowing. This ensures that the seed emergence rate is as high as 99%.
After exploring the variety of crops a corn planter can handle, it is crucial to understand the structure of the corn sowing machine. This knowledge optimizes its planting capabilities.
Structure of corn sowing machine
Planting box
PC material planting box is strong and durable, and not easy to bend.
Corn planting box has good toughness. The buckle is made of metal, the surface is galvanized, and it is not easy to rust.
Spraying part
The corn sowing machine’s body is processed by first grinding and then applying a high-temperature baked paint, ensuring strong adhesion and durability over time.
Sowing part
The height can be adjusted. The sowing depth of the seeder can be adjusted in a simple way.
The sowing depth and row spacing can be easily adjusted according to the instructions or videos.
The structure of the corn sowing machine plays a crucial role in ensuring the even distribution of corn seeds.
How to sow corn evenly?
The whole machine can change the plant spacing through the gearbox, which can produce four plant spacings. As long as the transmission ratio of the gearbox is changed, the plant spacing of each row of the entire machine can be changed.
The gearbox operating lever allows simultaneous control of the radial pendulum and axial movement of the pendulum wheel, ensuring fast and convenient operation. All gears of the gearbox are made of steel and have undergone carburizing treatment.
The frame is lifted from the ground. This widens the distance between the front and rear openers. As a result, it reduces wheat straw blockage in summer.
To achieve uniform distribution of corn seeds, the operational techniques are essential before delving into the specific parameters of the corn seeder machine.
Corn seeder machine parameters
| Model | 2BYSF-2 | 2BYSF-3 | 2BYSF-4 | 2BYSF-5 | 2BYSF-6 | 2BYSF-8 |
| Size | 1.57*1.3*1.2m | 1.57*1.7*1.2m | 1.62*2.35*1.2m | 1.62*2.75*1.2m | 1.62*3.35*1.2m | 1.64*4.6*1.2m |
| row | 2 | 3 | 4 | 5 | 6 | 8 |
| Row spacing | 428-570mm | 428-570mm | 428-570mm | 428-570mm | 428-570mm | 428-570mm |
| Plant spacing | 140mm-280mm | 140mm-280mm | 140mm-280mm | 140mm-280mm | 140mm-280mm | 140mm-280mm |
| Ditching depth | 60-80mm | 60-80mm | 60-80mm | 60-80mm | 60-80mm | 60-80mm |
| Fertilization depth | 60-80mm | 60-80mm | 60-80mm | 60-80mm | 60-80mm | 60-80mm |
| Sowing Depth | 30-50mm | 30-50mm | 30-50mm | 30-50mm | 30-50mm | 30-50mm |
| The capacity of the fertilizer tank | 18.75L x2 | 18.75L x3 | 18.75L x4 | 18.75L x5 | 18.75L x6 | 18.75L x8 |
| The capacity of the seedbox | 8.5L x 2 | 8.5L x 3 | 8.5L x 4 | 8.5L x 5 | 8.5L x 6 | 8.5L x 8 |
| Weight | 150kg | 200kg | 295kg | 360kg | 425kg | 650kg |
| Matched power | 12-18hp | 15-25hp | 25-40hp | 40-60hp | 50-80hp | 75-100hp |
| Linkage | 3-pointed | 3-pointed | 3-pointed | 3-pointed | 3-pointed | 3-pointed |
The parameters of the corn seeder machine directly influence its efficiency and precision during field operations, necessitating effective coordination with a tractor for optimal performance.
Corn sowing machine requires the use of a tractor
The corn sowing machine must be used with a tractor. Attach the corn planter to the tractor to operate it.
Different models of corn planters require tractors with varying horsepower. This ensures the tractor can power and move the planter.
Using a tractor with the corn sowing machine highlights its reliance on mechanized power, essential for field operations.
How does the corn planter machine work?
1. Metering Device Composition
The metering device consists of a guide wheel, diaphragm, device body, rows of scoop wheels, and a device cover. A partition is installed between the device body and the metering device cover to ensure stability.
2. Seed Scoop Wheel Installation
The corn seed scoop wheel is installed on the guide wheel, with a circular plate positioned between the row wheel and guide wheel. There is approximately 0.5mm clearance between them to prevent jamming during relative rotation.
3. Seed Filling Process
As the machine operates, seeds enter the metering device under the cover. In the filling area below, the scoop wheel fills with seeds. Both the scoop wheel and guide wheel rotate clockwise to ensure proper filling.
4. Seed Cleaning and Regulation
In the filling area, excess seeds are removed from the scoop holes and fall back into the filling area. When the scoop wheel rotates to the metering device, excess seeds are removed, ensuring only one seed per scoop.
5. Seed Release
As the scoop rotates, seeds are guided by centrifugal force and gravity into the corresponding guide wheel grooves. This ensures each scoop accurately deposits seeds into the seeding area.
6. Seed Placement
Seeds continue to move through the openings in the metering device shell. They fall into the opener, which creates a groove in the soil, completing the seed placement process.
Understanding how the corn planter machine operates provides insights into the numerous advantages it offers in agricultural practices.
Advantages of corn sowing machine
- High Seeding Precision. The seeding device has high seeding precision with a particle number qualification index exceeding 80%, ensuring accurate and consistent seed planting.
- High-Speed Operation. Capable of working at high speeds with normal filling, reaching up to 8 km/h when the plant spacing is at least 20 cm, allowing for faster and more efficient planting.
- Accurate Hole Spacing. Ensures precise hole spacing and even seedling distribution, reducing competition among plants and promoting vigorous crop growth, leading to higher yields.
- Convenient Gearbox Operation. The gearbox operation lever controls both the radial pendulum and axial movement of the pendulum wheel simultaneously, making the operation quick and convenient.
- Durable Gearbox Components. All gears in the gearbox are made from high-quality steel and carburized for enhanced durability, ensuring long-lasting performance.
- Reliable Transmission Parts. The transmission components are made of high-quality rolling bearings, providing reliable performance and ensuring the machine operates smoothly.
The advantages of the corn sowing machine highlight its efficiency and productivity benefits, addressing various challenges faced by growers in agricultural operations.
What problems do corn planters solve for growers?
This fully automatic corn planter enhances agricultural mechanization. It is more efficient for planting. It eliminates the inefficiency and high labor of using no tools or semi-automatic planters.
Avoid missing the best corn planting cycle due to production efficiency issues, affecting corn germination and growth. In addition, we also have semi-automatic corn planters, which are very suitable for small-production corn sowing.
The corn planters effectively address various challenges encountered by growers during the planting process. Understanding tips and maintenance for the maize planting machine is equally essential for optimal performance and longevity.
Tips and maintenance of maize planting machine
- Clean the machine thoroughly after each shift, removing soil and debris from different parts.
- Daily, clear any remaining fertilizer and seeds from the cylinder and lifter disc.
- Regularly check and tighten connections; address any looseness promptly.
- Inspect rotating parts for smooth operation; adjust or replace worn components as needed.
- Apply butter to sprocket slots every four hours of operation; lubricate chains and flywheels regularly.
Understanding the tips and maintenance of a maize planting machine ensures its longevity and efficiency, crucial considerations when deciding how to purchase the right maize planter machine.
